05 / Services
Fabrication
Made off-site, so site time stays short.
01Overview
Every hour of work moved from the plant into a workshop is an hour taken off the critical path, out of a permit window, and away from a congested working front.
Plejad fabricates pipe spools, steel assemblies, supports and secondary components to drawing, with the material identification and weld records the site will later ask for.
02Capabilities
What this discipline covers.
- 01Pipe spool fabrication from isometrics
- 02Steel assemblies, frames and skid structures
- 03Pipe supports, brackets and secondary components
- 04Cutting, forming, fitting and welding
- 05Material identification and traceability through fabrication
- 06Surface preparation and protective coating coordination
03Typical scope
Work packages typically contracted under this discipline.
- —Spool packages for a piping installation contract
- —Support and bracket batches for a pipe rack
- —Custom steel assemblies to project drawings
- —Replacement components for maintenance stock
- —Pre-assembly of modules for rapid site erection
Scope is confirmed per project. Capabilities listed here are indicative and adjusted to the specification, permit regime and client procedures of each site.
04Execution approach
How the discipline is planned, staffed and closed out.
01
Drawing to cut list
Fabrication starts from a checked cut list, so material is ordered once and nested efficiently.
02
Traceability maintained
Heat numbers and material marks are transferred at every cut so identification survives into the finished item.
03
Weld records
Welds are logged against welder and procedure as they are made, ready for the inspection level the project requires.
04
Delivered fit to install
Items are checked dimensionally and marked for their location before they leave the workshop.
05Where it applies
Sectors we can support
11Next step
Have a project in mind?
Send us the scope, the drawings or just the outline. We will come back with the trades, the sequence and a realistic view of the programme.
